Features

1. For cutting Bakelite Board, Plastic Sheet, Acrylic Sheet, Fiber Sheet and Wood Board.
2. The table and frame are foldable, space-saving, light weight, and easy to transport
3. The saw blade can move automatically for cutting operation.
4. The guide ways of the carriage are made of aluminum alloy.
5. Dust collector is equipped.
6. There is a safety lid on circular saw blade that it can raise springy while operation.
7. The speed of the saw carriage is adjustable with a a frequency converter.

Spec.
  • Item No.: MS-08-002
  • Main Saw Motor: 3 HP
  • Main Saw Blade Arbor: 25mm (1")
  • Spindle Rotation Speed: 7500 RPM
  • Dust Collector Motor: 1/2 HP
  • Saw Carriage Feed Motor: 4GN-12.5K
  • Saw Drive Belt: 422J
  • Saw Blade Diameter: 195mm ( 8 " )
  • Saw Carriage Feed Speed: 0~30m / Min Max.
  • Height of Cut: 50mm Max.
  • Length of Cut: 2450mm
  • G.W.: 78 KGS
  • N.W.: 70 KGS
  • Operation Dimension (L*W*H): 305 * 80 * 75 (cm)
  • Storage Dimension (L*W*H): 162 * 45 * 75 (cm)
  • Packing Carton Dimension (L*W*H): 175 * 50 * 90 (cm)
  • Packing Quantity: 20' Container Yd.- 28 sets 40' Container Yd.- 60 sets
